series10 Stainless Steel

Description

  • Housing made of robust stainless steel
  • Water-resistant
  • Configuration via IO-Link
  • With M12 or Wire Connection
  • Symbols illuminated
  • More at: series10.captron.com


APPLICATION: INDUSTRIAL AUTOMATION | FOOD & BEVERAGE | BUILDING TECHNOLOGY

  • Dimensions
    Ø 30 mm total diameter
    4 mm height
    Ø 22.5 mm mounting hole
  • Mounting
    Snap-In or mounting due to lock nut
  • Customized design
    Wide range of symbols and pictograms, including customized options
  • Customized software configuration
    LED-Colors, switch sensitivity, actuation type and time, output signals
  • IODDfinder (external link):
    + Go to IODDfinder CANEO series10
  • CANEO series10 Quick start guide
    + Show IODD video instruction

Downloads series10 Stainless Steel

csm_CANEO_series10_Standard-Stainless_Steel-BA_V1.2_en_fr_70cb820c08
CANEO series10 Standard/Stainless Steel Operating Instructions EN/FR

+ Download EN
csm_TRM_CANEO_series10_FW_V9.0_dc7220fd0c
TRM CANEO series10

+ Download DE
+ Download EN
+ Download PL
csm_thumbnails_CANEO_series_10_brochure_EN_e213743d0b
CANEO series10 Brochure

CANEO series

+ Download DE
+ Download EN
+ Download CN
+ Download PL
csm_thumb-CAPTRON-certificate-of-compliance-CSA_91d3ba7702
Certificate of Compliance - CSA

+ Download DE
+ Download EN
csm_CAPTRON-thumb-IO-Link-TRM_07a8d1eadd
CANEO series10 IO-Link TRM (Firmware V8.0)

+ Download DE
+ Download EN
+ Download CN
+ Download PL
csm_CAPTRON-manual-CANEO-series10_en_2bb3ff7fba
CANEO series10 Standard Operating manual

CANEO series

+ Download DE
+ Download EN
csm_thumb-CAPTRON-certificate-ece-r118_62db300f72
Certificate ECE-R118

+ Download DE
+ Download EN
+ Download PL
csm_CAPTRON-thumb-symbol-list-b_8f967bb16b
CANEO series10 symbol catalog (B)

+ Download DE
+ Download EN
+ Download CN
+ Download PL
csm_CAPTRON-thumb-symbol-list-c_386c3ab1ac
CANEO series10 symbols catalog (C)

+ Download DE
+ Download EN
+ Download CN
+ Download PL
csm_thumb-CANEO-series10-iolink-trm_56b58203de
CANEO series10 IO-Link TRM (Firmware V6.0)

csm_CANEO_fd397eb4a8
STEP: CANEO series10 Stainless Steel M12

+ Download DE
+ Download EN
+ Download CN
+ Download PL
csm_CANEO_fd397eb4a8
STEP: CANEO series10 Stainless Steel Strands (strands included)

+ Download DE
+ Download EN
+ Download CN
+ Download PL
csm_CANEO_fd397eb4a8
STEP: CANEO series10 Stainless Steel Strands

+ Download DE
+ Download EN
+ Download CN
+ Download PL

Service and Support

Request a quoteDownload centerTechnical support

Product Images

[Translate to Englisch:] CAPTRON CANEO series10 Stainless Steel

Technical Drawings

CAPTRON-drawing_1_CS10-Steel
CAPTRON-drawing_2_CS10-Steel

Application Images

CAPTRON-SENSORswitches-CS10-Steel-Application-002
CAPTRON-series10-Touch-Steel-Application-001

Housing colors

  • Edelstahl_01Housing stainless steel

Features

  • dynamicFunction: Dynamic (Signal length limited)
  • staticFunction: Static (permanent signal)
  • tffToggle Flip Flop
  • automaticAutomatic
  • manualManual
  • semi-automaticSemi-Automatic

Specifications

Supply voltage 24V DC
Output PNP-NC
PNP-NO
Operating temperature (24V DC)
-30°C...+65°C
Connection M12
Mounting method Mounting hole 22,5 mm
screw mounting
Housing material stainless steel (V4A)
IP protection level Front IP69K
IK level of protection IK08
Communication interface IO-Link V1.1
Switch surface material Polycarbonate (PC)

Suitable Accessories

CAPTRON-Accessoires-Mounting-Support-Connection-Cable-M12

Cable M12

M12 cable for sensor connection

  • Connector straight or angled
  • Different lengths are available
  • Differnt numbers of cores are available
  • Screw mounting
